RZ/V2L VERSA SOM
Mainstream, AI Accelerator
Dual-core
Arm Cortex-A55
Secure Boot
Crypto Engine
3D Graphics
Engine
AI & ML
Capabilities
Product Overview
The RZG2L VERSA SOM is a versatile System on Module featuring the Renesas RZ/G2L processor. It boasts a powerful 1.2GHz Dual Core Arm Cortex™-A55 processor with an Arm Cortex™-M33 co-processor, incorporates a 3D Graphics Processing Unit (GPU) for enhanced User Interface capabilities, and incorporates a DRP-AI accelerator for enhanced AI capabilities, providing an energy flex architecture and built-in security features. Designed for industrial applications, it includes three CAN-FD bus, Dual Gigabit Ethernets, and industrial temperature grade support. This compact module offers a wide array of peripherals and connectivity options, making it ideal for diverse embedded applications requiring robust performance, Graphical User Interface, and reliability.
Features
Optimized for Al and Vision
Entry level NPU and unlock new possibilities for artificial intelligence and computer vision applications.
Reliable, 200 PIN SODIMM Connector
Ensures robust mechanical integrity, streamlined manufacturing, and enhanced reliability in rugged industrial applications.
Industrial-Grade Reliability
Engineered for exceptional reliability and long-term operation in demanding industrial environments.
Rich I/O and Connectivity
Comprehensive I/O and industrial connectivity options enable seamless integration with a wide range of peripherals and field interfaces.
Specifications
Processor:
Processor: RZ/V2L
Architecture: Dual Arm Cortex-A55
Frequency: 1.2GHz
Sub Core: Arm Cortex-M33
Sub Core Frequency: 200MHz
NPU: DRP-AI Accelerator
Memory:
RAM: 1/2GB DDR4
eMMC: 4/8/16GB
QSPI FLASH: 8MB
Peripheral List:
7x UART
3x SPI
2x CAN-FD
4x I2C
2x USB 2.0 OTG
1x MMC/SD
Connectivity:
2x Gigabit Ethernets (one PHY on board)
Multimedia:
24-bit RGB Parallel Display
MIPI DSI
3D Graphics Processing Unit
MIPI Camera
4x SSI
Miscellaneous:
JTAG
Secure boot
Crypto Engine
Design Resources
Software Releases
Technology Use Cases
The robotics industry is advancing at a rapid pace—blending mechatronics, machine vision, and artificial intelligence to create autonomous, intelligent machines. Whether it’s …
In the fast-paced world of embedded systems, time-to-market, scalability, and reliability are critical. This is where System on Modules (SoMs) shine. A …
Resources
A feature-rich platform designed to accelerate the development and evaluation of applications built on the RZ/V2L VERSA SoM. It integrates the Renesas RZ/V2L processor with a 1.2GHz Dual Cortex™-A55 and a 200MHz Cortex-M33 real-time co-processor, along with an NPU for efficient AI processing at the edge.
