Modbus Gateway MBGWY00x
Scalable, Affordable
Dual Isolated
Modbus RTU Channels
Compact Din Rail
Mountable
10/100Mbps
Ethernet
4G LTE with
2G Fallback
Product Overview
Calixto MBGWY00x Modbus Gateway is an industrial-grade connectivity solution designed to collect data from Modbus TCP and Modbus RTU devices and securely transmit it to cloud platforms. Built for reliable and secure data exchange it ensures consistent communication between field devices control systems and cloud applications. An intelligent data logging mechanism preserves data during network interruptions enabling continuous data availability improved visibility and dependable connectivity for scalable industrial IoT deployments.
Features
Protocol Flexibility
Built for secure cloud communication with the flexibility to adapt across industrial and IoT deployments.
Quick and Easy setup
Easy configuration using an integrated web tool for fast setup and hassle-free commissioning.
Industrial-Grade Reliability
Engineered for exceptional reliability and long-term operation in demanding industrial environments.
Robust & Isolated Design
Reliable RTU channels and 10/100 ethernet designed to perform consistently in demanding industrial applications.
Specifications
Network Interface:
- Ethernet Port: 1x 10/100BASE-T(X) RJ-45
- Cellular: 4G, 2G Fallback, External Antenna, Micro SIM
Serial Interface:
- Ports: 2
- Mode: RS485(Isolated)
- Baud Rate: 50 bps ~ 921.6 kbps
- Parity: None, Odd, Even
- Data Bits: 7,8
- Stop Bits: 1,2
Power Characteristics:
- Input Voltage: 12/24 Vdc
- Power Consumption: 2W
- Reverse Polarity Protection: Yes
Environmental Limits:
- Operating Temperature: -10 ~ 60 degC
- Storage Temperature: -20 ~ 80 degC
- Operating Relative Humidity: 5 ~95% RH
Software:
- Configuration: Webserver
- Protocols: TCP, IPv4, DHCP Client, HTTP(S), MQTT(S)
- Modbus: TCP,RTU
- Modbus devices: 32 devices on each channel, Total 96 Devices (RTUx2 + TCP)
Physical Specification:
- Housing: ABS Plastic
- Dimensions (W x H x D): 72.00 x 122.50 x 34.00
- Weight: ~0.80 Kg
- Mounting: Din Rail
